CONSTRUCTION
- Frame: 304 SS
- NEMA certified control box
- Membrane housing: 304 SS
- Piping : 304 SS
KEY FEATURES
- Programmable logic controller (PLC)
- 4 to 10 membranes 8’’ X 40’’
- 2 adjustment valves: concentration & pressure
- 3 pressure gauges: before / after pre-filters and on the membranes pressure operation
- Automatic 304 SS solenoid inlet
feed valve - 2 flow meters: permeate & concentrate with sampling valves
- Low feed pressure protection
- High temperature protection
- Sediment pre-filters 20”, 5 microns
- Low energy consumption
- Designed for cold water operation
OPTIONS
- Conductivity meter and temperature indicator
- SS membranes washing tank (CIP) with valves kit
- Raw water fast flush rinse cycle
- Automatic permeate flush
- Touch screen
- Web access (VPN) for remote web control
- 600 volts / 3 phases option
- Flow meter with sampling valve on each membranes housing
MADE IN CANADA.
